R24

R24 combina un registratore multitraccia a 24 tracce, una interfaccia audio, un controller MIDI, una drum machine ed un lettore di campioni. Una potente e compatta macchina da studio pronta a catturare ed ampliare ogni sfumatura della vostra creatività musicale. Cubase LE5, incluso nella confezione, espande di fatto la versatilità del registratore R24 offrendo al concetto di "home recording" un nuovo standard qualitativo.

Specifiche Tecniche

Physical Tracks: 24
Simultaneous Recording Tracks: 8
Simultaneous Playback Tracks: 24
Recording Data Format: 44.1/48kHz, 16/24bit WAV
Maximum Recordable Time: 200 minutes / GB (44.1kHz 16-bit, mono tracks)
Projects: 1,000
Markers: 100 / Project
Locator: Hours / Min. / Sec. / msec or Bars / Beats / Ticks
File Editing: Divide, Trim
Other Functions: Punch-In / Out (Manual, Automatic), Bounce, A-B Repeat, Undo / Redo, Metronome
Input Channels: 8
Output Channels: 2
Quantization: 24bit
Sampling Frequency: 44.1, 48, 88.2, 96kHz
Faders: 9
Level Meters: 4-Segment LED
Track Parameters: 3-Band Equalizer, Pan (Balance), Effect Send x 2, Invert
Stereo Links Track pairs: 1/2 to 23/24 selectable
Algorithms: 9 (clean, distortion, eco / bass sim, bass, mic, dual mic, stereo, 8 x comp eq, mastering)
Types: 150
Modules: 7 for Insert, 2 for Send / Return
Patches: 330 for Insert, 60 for Send / Return
Tuner: Chromatic, Guitar, Bass, Open A/D/E/G, D modal
Playback Data Format: 44.1/48kHz, 16/24bit WAV
Voices: 24
Editing Functions: Trim, Time-stretch
Voices: 8
Sound Format: 16-bit Linear PCM
Drum Kits: 10
Pads: 8 (velocity-sensitive)
Precision: 48 PPQN
Rhythm Patterns: 511/project
Patterns: 511 (472 factory, 39 blank) / Project
Beat: 1/4 - 8/4
Tempo: 40.0 - 250.0 BPM
Recording Media: SD Card (16MB-2GB), SDHC Card (4-32GB)
A/D Conversion: 96kHz 24bit delta-sigma ADC
D/A Conversion: 96kHz 24bit delta-sigma DAC < LI>Display: 128 x 64 pixel LCD (with backlight)
Inputs: 8 x XLR-1/4''Phone Combo Jack / Input Impedance: (Balanced input) 1k? balanced, 2nd hot, (Unbalanced input) 50k? unbalanced, (Hi-Z Input) 470k? / Input

Level: -50dBm to +4dBm continuously variable
Built-in microphones: Omnidirectional condenser microphones Gain: -50dBm to +4dBm continuously variable
Phantom Power Supply: 48V / 24V
Master Output: 1/4"TRS Phone (balanced) / Output Impedance: 1k? / Rated Output Level: +4dBm
Headphones Output: 1/4''Stereo Phone Jack, 20mW x 2 (at 32? load)
USB: B type (USB2.0 High-Speed compatible) Audio Interface / Control Surface or Mass Storage Class operation A type (USB2.0 High-Speed compatible) USB Host capability
Power Requirements: AC adaptor (DC5V/1A/center positive) or AA size (LR6) battery x6
Battery Life: 4.5 hours (with backlight on and phantom power off)
Dimensions: 376(W) x 237.1(D) x 52.2(H) mm
Weight: 1.3kg (without batteries)
